Doughty Swivel Coupler (Black)

Internal coupler for joining two lengths of 48mmØ scaffold tube end to end.

Manufactured from high tensile Aluminium Extrusion. SWL: 750 Kg Tube Diameters: 48 to 51mm Width: 50mm Tube Centres: 110mm Weight: 1.33 Kg

A high tensile extruded aluminium trigger clamp that is suitable for 48mm to 51mm diameter tubes. Has a WLL of 200Kg and is 30mm wide, factory fitted with a 29mm Spigot receiver designed to accept a 28mm diameter spigot. Supplied with lynch pin for secondary locking allowing 360 degree rotation, this clamp is designed predominantly for use in the TV/Film industry and is often used with Drop Arms and Pantographs.

External coupler for joining two 48mm Pipes end to end

A steel adjustable clamp specifically designed for use in clear span marquees using grooved aluminium kader style beams. It has M10, M12 and M14 tapped mounting points.

A steel double ended 90 degree twist hook clamp suitable for 48mm to 51mm diameter tube available in various sizes. Zinc plated finish.

A hook clamp designed to take a 28mm TV Spigot

The Doughty Hanging Clamp is supplied fitted with an Eye nut. This Clamp is ideal for suspending wire hung loads. Manufactured from high tensile Aluminium Extrusion. SWL: 340 Kg Tube Diameters: 48 to 51mm Width: 50mm Fixings: M12 Eye Nut Weight: 0.84 Kg

Aluminium Pipe to Pipe coupler SWL 200kg (vertical loads only!)

A steel double ended parallel hook clamp available in various sizes. Zinc plated finish.

Swivel clamp for 48mmØ Scaffold Tube
