Strand Patt. 23 Profile Spot

Powerful open-faced floodlight with a moving reflector focusing mechanism to vary the beam from 23° to 70° with even light distribution.

A lightweight revolution in quartz lighting, constructed from fiberglass/polyester, provides the benefit of strength and light weight with almost total heat insulation. Variable zoom from 42° spot to 82° flood.

APPLICATIONS The Pattern 123 Fresnel Spotlight is used whenever it is required to build up an area of light to a much greater level without however defining the edges of the beam. The size of the peak area to be lit can be adjusted accurately by means of the knob under the lantern and the soft edges of the beam will ensure a gentle transition from one lighting level to another. The lantern may also be regarded as an adjustable flood to provide wide but ne~ertheless localised coverage. The Pattern 123 is ideal for stage lighting on the stage itself…

This spotlight embodies the beam characteristics of both the Profile and Fresnel spotlights in one compact unit. It provides accurate control of beam shape with hard-edge cut-off on any one or more sides of the beam with indeterminate soft-edges on the remaining sides. It projects an image of the gate aperture which has two sets of four built-in masking shutters – one set, in focus, for hard-edges and another alternative set, out of focus, for soft-edges. Two lens combinations are available so that the most efficient use can be made of the light collected at the gate by an ellipsoidal…
